Flush Mounting type
Used to measure Multi-Point temperature
Sizes : 96 x 96 mm sq
Display : 3-1/2 Digits Seven
Segment Red LED display
Cold Junction Compensation: Automatic for Thermocouple
Open Sensor Indication
Sensor Input : J, K, R, S, T/C, PT-100 RTD, V & 4 – 20mA
Accuracy : J,K 1%; R,S 0.5%; PT-100 RTD 0.2%, mV,V,mA 0.1%
Number of Sensor Inputs : 6 by Rotary Switch
Auxiliary Power Supply : 230V Single Phase AC 50Hz.
